ANTILEAK 303 Expanded PTFE Round Rope

Descriptions:

Expanded PTFE Round Rope is the round shape rope that made from imported PTFE raw material. It has all the properties of PTFE and resistant to almost all corrosive media. It’s the ideal substitute of the V shape seal and other braided gland packing.

Features:

Soft, twistable and bendable, easily to be used and replaced

Excellent sealing property

Excellent anti-wriggle variation property and cold current resistance, long service life

Environmental protection, no pollution

General specifications can be used in numerous equipments, reduce the storage and save money

Applications:

Expanded PTFE Round Rope is applicable for pipeline valves in food industry, chemical plant, breweries, oil refinery, etc.

Available dimensions:

Diameter: 2.0 ~ 20 (mm)

Length will be customized according tocustomer’s request.

Technical Data:

Working temperature: -260℃~ +260℃

Working pressure: 200kgf/cm2 in the liquid sealing, 140kgf/cm2 in the gas sealing

Density: 0.8 g/cm3
